2023

Dual Purpose Tire & Front Double Disc Brake

ADJ. PRO-LINK REAR MONOSHOCK

Inverted Front Suspension

New Headlight Design

750cc SOHC IN-LINE TWIN CYLINDER ENGINE

New Honda RoadSync

NEW WINDSCREEN DESIGN

5” TFT Panel Meter

5 Riding Mode

	XL750 Transalp
Engine Type	4-stroke 8-Valve SOHC Parallel Twin with 270° Crank and Unicam
Cooling System	Liquid Cooled
Fuel Supply System	PGM-FI
Displacement	755 cc
Bore x Stroke	87 x 63.5 mm
Compression Ratio	11 : 1
Maximum Power (Crankshaft)	67.5 kW / 9,500 rpm
Maximum Torque (Crankshaft)	75 Nm / 7,250 rpm
Transmission	6-speed Manual
Starting System	Electric
Clutch System	Wet multiple, Assist/Slipper clutch
Oil Capacity	3.4 L (Exchange)

	XL750 Transalp
Frame Type	Diamond, Steel
Front Tire Size	90/90-21 [54H]
Rear Tire Size	150/70-18 [70H]
Brake System	ABS 2 Channel
Front Brake Type	Hydraulic, 310 mm Double Wavy Disc
Rear Brake Type	Hydraulic, 256 mm Single Wavy Disc
Front Suspension Type	Showa, 43 mm Adjustable Inverted Telescopic Suspension
Rear Suspension Type	Swing Arm with Showa, Pro-Link Adjustable Monoshock

	XL750 Transalp
Ignition Type	Full Transisterized
Battery	12V-8.6Ah
Spark Plug Type	NGK SILMAR8A9S
Headlight	LED
Security	HISS (Honda Ignition Security System)

1800/2018

FOG LAMP

NAVIGATION SYSTEM

PREMIUM AUDIO SYSTEM

7-SPEED AUTOMATIC DCT

1800cc with Horizontally Opposed Six-Cylinder

SUPPORT APPLE CARPLAY & ANDROID AUTO

Electrical Adjustable Wind Screen

All LED Lighting System

Double Wishbone Fr. Suspension

Electronic C-ABS

AIRBAG

THROTTLE BY WIRE WITH RIDING MODE

Engine Type	Horizontally Opposed Six-Cylinder
Cooling System	Liquid Cooled
Fuel Supply System	Fuel Injection (PGM-FI)
Displacement	1.833 cc
Bore x Stroke	73mm x 73mm
Compression Ratio	10,5 : 1
Maximum Power	93 kW / 5.500 rpm
Maximum Torque	170 Nm / 4.500 rpm
Transmission	Seven-Speed Automatic DCT, Plus Reverse and Walking Mode
Starting System	Electric
Clutch System	Wet, Multiple With Coil Springs
Oil Capacity	4,4 L (periodic exchange)

Frame Type	Diamond Twin Tube Type, Alumunium
Front Tire Size	130/70R-18 M/C 63H
Rear Tire Size	200/55R-16 M/C 77H ABS
Front Brake Type	320 mm x 4,5 mm Dual Hydrauilic Disc With 6-piston Calliper, Floating Rotors and Sintered Metal Pads
Rear Brake Type	316 x 11 mm Ventilated Disc With 3-Piston Calliper, and Sintered Metal Pads
Brake System	ABS
Front Suspension Type	Double Wishbone
Rear Suspension Type	Pro Arm Single-Side Swingarm Sith Pro-Link Single Shock With Computer Controlled
