STEP UP

TO ADVENTURE

Engine Type	4 Stroke, DOHC, Parallel Twin Cylinder
Displacement	471 cc
Cooling System	Liquid Cooled
Fuel Supply System	PGM-FI (Programmed Fuel Injection System)
Bore x Stroke	67 x 66,8 mm
Compression Ratio	10,7 : 1
Max. Power	37 kW / 8.500 rpm
Max. Torque	44,6 Nm / 6.500 rpm
Transmission	Constant Mesh, 6 speed
Starting System	Electric
Clutch System	Multiple Wet Clutch with Coil Spring
Oil Capacity	2,4 L [Periodic Exchange]
Gear Shift Pattern	1 - N - 2 - 3 - 4 - 5 - 6
Lubricant Type	Wet, Pressing and Spray

Frame Type	Diamond, Steel
Front Tire Size	110/80ZR 19 M/C [59H]
Rear Tire Size	160/60ZR 17 M/C [69H]
Front Brake Type	Hydraulic, 296 mm double disc with dual piston calipers
Rear Brake Type	Hydraulic, 240 mm single disc with single piston calipers
Brake System	ABS 2 Channel
Front Suspension Type	Showa, 41 mm SFF-BP Inverted Telescopic Fork
Rear Suspension Type	Swing arm, adjustable Showa monoshock with Prolink

Ignition Type	Full Transisterized
Battery	MF-Wet 12V - 7 Ah
Spark Plug Type	NGKCPR8EA-9
Headlight	High 20W - Low 12W [LED]
Security	HISS [Honda Ignition Security System]
