BORN TO RACE

1000CC DOHC INLINE - FOUR CYLINDER

PRODUCT FEATURE

COLOR VARIANT

Rp. 828.965.000

Honda Tricolor

SPECIFICATION DETAIL

ENGINE
DRIVE TRAIN
CHASIS
DIMENSION
ELECTRICAL

	CBR1000RR-R
Engine Type	4-stroke 16-valve DOHC Inline-4
Displacement	999.9
Cooling System	Liquid Cooled
Fuel Supply System	PGM-DSFI
Bore x Stroke	81 x 48.5 mm
Compression Ratio	13.6:1
Maximum Power	160 kW / 14,000 rpm
Maximum Torque	113 Nm / 12,000 rpm
Starting System	Electric
Clutch System	Multiplate Wet Clutch with Coil Spring
Oil Capacity	2.8 L (periodic exchange)

	CBR1000RR-R
Transmission	Manual, 6-speed
Gear Shift Pattern	1 - N - 2 - 3 - 4 - 5 - 6
Final Drive	Chain

	CBR1000RR-R
Frame Type	Aluminium Composite Twin Spar
Front Tire Size	120/70ZR17M/C (58W)
Rear Tire Size	200/55ZR17M/C (78W)
ABS System	2 Channel
Front Brake Type	330 mm disc Radial-Mount 4-piston Nissin Caliper
Rear Brake Type	220 mm disc with 2-piston Brembo Caliper
Front Suspension Type	Showa BPF 43 mm Inverted Telescopic Suspension with preload, compression and rebound adjustment, 120 mm stroke
Rear Suspension Type	Showa BFRC-Lite Pro-Link Monoshock with 10 step preload, stepless compression and rebound damping adjustment, 143 mm stroke

	CBR1000RR-R
Overall	(L X W X H) 2.100 x 740 x 1.140 mm
Wheelbase	1.450 mm
Ground Clearance	130 mm
Seat Height	830 mm
Curb Mass	200 kg
Fuel Tank Capacity	16,5 L

	CBR1000RR-R
Ignition Type	Full Transisterized, Battery
Battery	12V-2.3Ah (20h)
Spark Plug Type	NGK SILMAR10C9S
Headlight	LED
Security	Honda Smart Key System
