FEATURES
& COMPARISON

Honda CBR1000RR-R

2019

SEE DETAIL

TFT PANEL METER

---

HONDA SMART KEY SYSTEM

---

ADJUSTABLE INVERTED FRONT SUSPENSION

---

1000cc DOHC INLINE – FOUR CYLINDER

---

2-MOTOR THROTTLE BY WIRE, RIDING MODE, ABS MODE, START MODE

---

HONDA ELECTRONIC STEERING DAMPER

---

	CBR1000RR-R
Engine Type	4-stroke 16-valve DOHC Inline-4
Displacement	999.9
Cooling System	Liquid Cooled
Fuel Supply System	PGM-DSFI
Bore x Stroke	81 x 48.5 mm
Compression Ratio	13.6:1
Maximum Power	160 kW / 14,000 rpm
Maximum Torque	113 Nm / 12,000 rpm
Starting System	Electric
Clutch System	Multiplate Wet Clutch with Coil Spring
Oil Capacity	2.8 L (periodic exchange)



---

	CBR1000RR-R
Transmission	Manual, 6-speed
Gear Shift Pattern	1 - N - 2 - 3 - 4 - 5 - 6
Final Drive	Chain

---

	CBR1000RR-R
Frame Type	Aluminium Composite Twin Spar
Front Tire Size	120/70ZR17M/C (58W)
Rear Tire Size	200/55ZR17M/C (78W)
ABS System	2 Channel
Front Brake Type	330 mm disc Radial-Mount 4-piston Nissin Caliper
Rear Brake Type	220 mm disc with 2-piston Brembo Caliper
Front Suspension Type	Showa BPF 43 mm Inverted Telescopic Suspension with preload, compression and rebound adjustment, 120 mm stroke
Rear Suspension Type	Showa BFRC-Lite Pro-Link Monoshock with 10 step preload, stepless compression and rebound damping adjustment, 143 mm stroke

---

	CBR1000RR-R
Overall	(L X W X H) 2.100 x 740 x 1.140 mm
Wheelbase	1.450 mm
Ground Clearance	130 mm
Seat Height	830 mm
Curb Mass	200 kg
Fuel Tank Capacity	16,5 L

---

	CBR1000RR-R
Ignition Type	Full Transisterized, Battery
Battery	12V-2.3Ah (20h)
Spark Plug Type	NGK SILMAR10C9S
Headlight	LED
Security	Honda Smart Key System

---

Honda Rebel 1100

2024

SEE DETAIL

FULL DIGITAL PANEL METER

---

Cruise Control

---

RIDING MODE & HSTC

---

ALL LED LIGHTING SYSTEM

---

ALL LED LIGHTING SYSTEM

---

ADJUSTABLE 43MM TELESCOPIC SUSPENSION

---

DUAL CLUTCH TRANSIMISSION

---

ADJUSTABLE TWIN PIGGYBACK REAR SHOCK

---

Dimension	2.240 x 834 x 1.115 mm
Wheel Base	1.520 mm
Ground Clearance	120 mm
Seat Height	700 mm
Curb Mass	233 kg
Fuel Tank Capacity	13,6 L

---

Engine Type	SOHC 8-valve parallel twin with 270 crank and uni-cam
Displacement	1084 cc
Cooling System	Liquid Cooled
Fuel Supply System	PGM-FI (Programmed Fuel Injection System)
Bore × Stroke	92 x 81,5 mm
Compression Ratio	10.1 : 1
Max. Power	64 KW/7.000 rpm
Max. Torque	98 Nm/4.750 rpm
Transmission	6 Speed, DCT
Starting System	Electric
Clutch System	2 Multiplate Wet Clutches with Coil Spring
Lubrication Type	Dry (Pressing and Spray)
Oil Capacity	4 L periodic exchange

---

Frame Type	Diamond Type, Steel
Front Tires	130/70B18M/C (63H)
Rear Tires	180/65B16M/C (81H)
Front Brake	Radial Mounted Monoblock 4-piston Brake Caliper, 330mm Floating Single Disc - ABS
Rear Brake	Single Piston Caliper, 256mm Single Disc - ABS
Brake System	ABS 2 Channel
Front Suspension	43mm Showa Telescopic Front Suspension, Adj
Rear Suspension	Showa Twin Piggyback Suspension, Adj

---

Ignition Type	Full Transisterized, Battery
Batttery	MF-Wet 12V 11,2Ah (10H)
Spark Plug Type	NGK SILMAR8A9S
Headlight	LED

---
